7-20

CHAPTER 7

The bucket seat slider needs periodic inspection

and maintenance. Loosen the swivel knob located

on the slider and pull the slider off the pedestal.

Inspect all fasteners and metal for fatigue.

Lubricate the points shown in the illustration with

a marine type grease. type of grease will not run

off under warm temperatures. Use a paint brush

to apply the grease. Also, use silicone spray for

areas that can not be accessed with the grease. Reassemble slider to

pedestal with the delrin cup positioned correctly.

LUBRICATE ALL

SPLINES

LUBRICATE SLIDER PLATE

CHECK FASTENERS

FOR TIGHTNESS

HANDLE

HANDLEHANDLE

LUBRICATE

HANDLES &

BOLT

BOLT

BUCKET SEAT SLIDER MAINTENANCE

Seating

7-20

CHAPTER 7

The bucket seat slider needs periodic inspection

and maintenance. Loosen the swivel knob located

on the slider and pull the slider off the pedestal.

Inspect all fasteners and metal for fatigue.

Lubricate the points shown in the illustration with

a marine type grease. type of grease will not run

off under warm temperatures. Use a paint brush

to apply the grease. Also, use silicone spray for

areas that can not be accessed with the grease. Reassemble slider to

pedestal with the delrin cup positioned correctly.

LUBRICATE ALL

SPLINES

LUBRICATE SLIDER PLATE

CHECK FASTENERS

FOR TIGHTNESS

HANDLE

HANDLEHANDLE

LUBRICATE

HANDLES &

BOLT

BOLT

BUCKET SEAT SLIDER MAINTENANCE

Seating
